Product Description
Description & Features
With a piston for the disc, the seat design of piston check valve is similar to a globe valve. It has a dashpot made of a cylinder and piston that acts as protection during application.
It is mainly used with angle and globe valves in piping systems that have periodic changes in flow directions. It is also used in high-pressure applications that have high flow velocity. Well-suited for installation in both vertical and horizontal pipelines with upward flow. It is commonly used in air, water, and steam systems.
● Replaceable seat.
● A variety of body and interior materials.
● The design of piston and valve seat, acting on the piston back pressure, sealing performance is excellent.
● These valves are unidirectional valves and restrict flow from opposite direction.
Specifications
| Size Range | Body Material |
1 1/4"-8" DN32-DN200 | WCB, LCB, WC6, CF8 |
| Pressure Rating | Disc Material |
Class150-Class600 PN16-PN100 | WCB, LCB, WC6, CF8 |
| End Connection | Seat Material |
| Flange (FF, RF, RJ), Butt Welding | A105+F6a, A105+STL6, 304, 316, Hastelloy, Monel, etc. |
| Structure Style | Stem Material |
| Full Port | / |
| Actuator Options | Design Standard |
| / | GB/T 12235 |
| Temperature Range | Face to Face Standard |
| -196℃~650℃ | GB/T 12221, GB/T 15188.1 |
| Connection Standard | Test Standard |
Flange Drilling: ASME B16.5, ASME B16.47, GB/T 9113, JB/T 79 Butt Weld: ASME B16.25, GB/T 12224 | JB/T 9092, GB/T 13927 |
