Product Description
Pindee Fittings can supply the butt weld steel elbow of long radius & short radius elbow 90 deg ,long radius elbow 45 deg, long radius & short radius elbow 180 deg ( return bend ), reducing elbow according to b16.9, mss-sp-43, b16.11 and mss-sp-97, din2605-2617 , for oil or gas pipeline, by galvanization painting or oiled lightly coating, also we can develop the new elbow mould as per your drawing or sample.
45° Elbow Black Paint Seamless Buttweld Dimensions
| Size | O.D | B | Size | O.D | B | Size | O.D | B |
| 1/2" | 21.3 | 16 | 6" | 168.3 | 95 | 28" | 711 | 438 |
| 3/4" | 26.7 | 19 | 8" | 219.1 | 127 | 30" | 762 | 470 |
| 1" | 33.4 | 22 | 10" | 273 | 159 | 32" | 813 | 502 |
| 1 1/4" | 42.2 | 25 | 12" | 323.8 | 190 | 34" | 964 | 553 |
| 1 1/2" | 48.3 | 29 | 14" | 355.6 | 222 | 36" | 914 | 565 |
| 2" | 60.3 | 35 | 16" | 406.4 | 254 | 38" | 965 | 600 |
| 2 1/2" | 73 | 44 | 18" | 457 | 286 | 40" | 1016 | 632 |
| 3" | 88.9 | 51 | 20" | 508 | 318 | 42" | 1067 | 660 |
| 3 1/2" | 101.6 | 57 | 22" | 559 | 343 | 44" | 1118 | 695 |
| 4" | 114.3 | 64 | 24" | 610 | 381 | 46" | 1168 | 727 |
| 5" | 141.3 | 79 | 26" | 660 | 406 | 48" | 1219 | 759 |
Pindee Butt weld Carbon Steel Fittings
| Diameter Range | 1/2”-48” |
| Type | Long Radius, Short Radius, Reducing Butt Weld Steel Elbow |
| Standard | B16.9,MSS-SP-43,B16.11, MSS-SP-97,DIN2605-2617 |
| Material | Carbon Steel: ASTM A234 WPB,WPC, ASTM,ASME A860 WPHY 42,WPHY 46, WPHY 52, WPH 60, WPHY 65, WPHY 70 |
| Low Temperature: A420 LF1,LF3, LF6, WPL3, WPL6, WPL9 | |
| Alloy Steel: ASTM A234 WP1,WP2,WP5,WP9,WP11,WP12,WP22,WP91,WP92 | |
| Stainless Steel: ASTM A403 WP304,WP304L,WP304H,WP310S,WP316,WP316L,WP321,WP321H,WP904L. | |
| Duplex Steel: A815,S31803,S32750,S32760,S31254,S34565,S31500,S32304 | |
| Non Ferrous Alloy: ASTM B366 | |
| Surface | Zinc-plated, Hot dipped galvanized, Painting, Oiled lightly and etc |
| Usage | The products are widely applied in such fields as petrochemical industry, fertilizer, nuclear power, boiler,ship,environmental protection, aviation, pulp and paper, food, medicine and etc |
| Equipment and Inspection | Portable Spectrometer, Brinell’s Machine, Ultrasonic Flaw Detector, Portable Sclerometer |
| We have gotten the approval of Takreer, Borouge, NPCC, FERTIL, NAKHEEL, ADNOC - UAE and Aramco - KSA. | |
| We can provide MTC as per EN10204 3.1, and also can do EN10204 3.2 certificate as per your requirement. | |
